HANDLEBAR Radio, Neon Pro, hydroformed multiple butted & heat-treated cr-mo
GRIPS Radio, Xenon, diamond knurling, clamp on grip, 139mm length
STEM Radio, Neon Pro, top loader, ext. 54mm, cnc machined, alloy
HEADSET Radio, Pro, Int. Headset, sealed, threadless, 1-1/8″ – 1.5″
BRAKE LEVER Radio, Raceline, hydraulic disc brake 2 finger lever
BRAKE Radio, Raceline, hydraulic disc brake, 120mm rotor
CRANK Radio, Xenon Pro, 2pc crank, cold forged/cnc, alloy 180mm length, 24mm spindle
BB Radio, Raceline, BSA24, external bearing cups, cnc machined, sealed
PEDALS Radio, Xenon Slim, alloy
CHAIN KMC, Z1eHX, 1/2″ x 3/32″
SPROCKET Radio, Xenon Pro, 44T, alloy
DRIVER Radio, 16Tcog, 1/2″- 3/32″, sealed cassette driver
FRONT HUB Radio, Turbine, alloy cnc, fully sealed, 36T, 3/8″ female cr-mo axle
REAR HUB Radio, Turbine, alloy cnc, fully sealed, 36T, disc brake cassette, 3/8″ female cr-mo axle
RIMS Radio, Argon Pro, 36H, alloy, flash welded, tubeless ready f&r
SEAT Radio, Xenon, pivotal, no padding
SEAT POST Radio, 27.2mm, pivotal, alloy seatpost
SEAT CLAMP Radio, Helium Pro, quick-release , alloy
TIRES Radio, Oxygen, front 20″x1.95″ / rear 20″x1.75″, foldable , tubeless ready
WEIGHT: 9.085kg/ 20.03lbs
FRAME GEOMETRY
TOP TUBE LENGTH 21.75″
CHAIN STAY LENGTH 15.25″
HEAD TUBE ANGLE 74°
SEAT TUBE ANGLE 71°
BOTTOM BRACKET HEIGHT 11.6″
HANDLEBAR GEOMETRY: -RISE 8.5″ -WIDTH 29″ -BACKSWEEP 6.5° -UPSWEEP 2.5°
